| Machine weight | 2300 kg |
| Engine Power | 36,4/49 kW/hp |
| Type of lift | Radial |
| Engine Power | 36 kW |
| Engine Power | 49 hp |
| Engine Torque | 143 N·m |
| Engine Manufacturer | Perkins |
| Engine Emission regulation | Tier 3 |
| Capacity | 2.2 l |
| No cylinders | 4 |
| Engine Air Induction | Natural |
| Fuel system | Mechanical |
| Transmission Type | Hydrostatic |
| Travel speed | 12.7 km/h |
| Auxiliary Hydraulics Pressure | 210 bar |
| Standard flow | 59 l/min |
| Rated operating capacity | 590 kg |
| Tipping load | 1179 kg |
| Bucket breakout force | 18.6 kN |
| Loader arm breakout force | 12.7 kN |
| Tyre size, in | 10 x 16.5 |
| Transport Dimensions, Length | 3.2 m |
| Transport Dimensions, Width | 1.5 m |
| Transport Dimensions, Height | 1.9 m |
| Machine weight | 2300 kg |
| Engine Power | 36,4/49 kW/hp |
| Type of lift | Radial |
| Engine Power | 36 kW |
| Engine Power | 49 hp |
| Engine Torque | 143 N·m |
| Engine Manufacturer | Perkins |
| Engine Emission regulation | Tier 3 |
| Capacity | 2.2 l |
| No cylinders | 4 |
| Engine Air Induction | Natural |
| Fuel system | Mechanical |
| Transmission Type | Hydrostatic |
| Travel speed | 12.7 km/h |
| Auxiliary Hydraulics Pressure | 210 bar |
| Standard flow | 59 l/min |
| Rated operating capacity | 590 kg |
| Tipping load | 1179 kg |
| Bucket breakout force | 18.6 kN |
| Loader arm breakout force | 12.7 kN |
| Tyre size, in | 10 x 16.5 |
| Transport Dimensions, Length | 3.2 m |
| Transport Dimensions, Width | 1.5 m |
| Transport Dimensions, Height | 1.9 m |
CASE Skid Steer Loaders. В Series
The CASE B Series compact track loaders offer a completely re-imagined operator interface and environment to simplify operation and put more power and control into the hands of the operator — including an 8-inch LCD multi-function display and simple electro-hydraulic controls.
Большие стекла, через которые открывается круговой обзор при любых условиях эксплуатации машины
Низкий порог обеспечивает самый удобный в классе доступ в кабину и уменьшенные основания под электрогидравлические органы управления
Опоры погрузочного оборудования, расположенные в нижней части рамы, повышают показатели машины при погрузке материалов
Простота подключения и отключения гидравлических шлангов навесного оборудования
Все точки технического обслуживания сгруппированы для облегчения ежедневных операций обслуживания
Оптимизированная процедура запуска машины для интуитивного понятного управления
Улучшенная компоновка для полного контроля машины
Возможность для подключения интерфейса Bluetooth, iPod/iPhone, USB – разъем и измененный подстаканник
Более узкий хват и уменьшенная верхняя часть джойстиков для большего комфорта оператора
Более стабильное движение по прямой на машинах с электрогидравлическими органами управления
Large cab windows, providing all around visibility in any operating conditions of the loader
Lower threshold provides best-in-class access to the cab and conveniently positioned electro-hydraulic controls
The radial-lift pattern is designed for operating buckets and other attachments at ground level, for digging and pushing
The vertical-lift pattern is designed for lift-and-carry and loading jobs
Loader stops, located in the lower part of the frame, increase equipment performance during loading
Easy to connect and disconnect hydraulic hoses for attachments
All service points are grouped make daily maintenance operations easy
Optimized loader start-up procedure for self-intuitive controls
Improved layout for full loader control
Bluetooth, iPod/iPhone, USB options and redesigned cup holder
Narrower grip and smaller upper joystick part for greater comfort of operator
Smoother straight movement on hydraulic control loaders
| Rated Operating Capacity 50% | 590 KG |
| Tipping load | 1179 KG |
| Lift Cylinder Breakout Force | 12,7 kN |
| Bucket Cylinder Breakout Force | 18,6 kN |
| Engine Brand | ISM |
| Engine Model | N844L-D-48SL-ROW |
| Displacement | 2,2 l |
| Horsepower | 36,4/49 kW/hp at 2800 rpm |
| Peak torque | 143 nM at 1800 rpm |
| Low Range | 12,7 km/h |
| High Range (Optional) | 18,0 km/h |
| Pump Flow | 59 LPM |
| High Flow | - LPM |
| Relief Pressure | - LPM |
| Operating Weight | 2300 KG |
| Shipping Weight | 2160 KG |
| Fuel Tank | 60,5 L |
| Engine Oil | 7,1 L |
| Hydraulic system oil, with filter | 29,2 L |
| Chain tanks, per side | 6,25 L |
| Coolant | 15,6 L |
| Alternator | 14, 120 V, A |
| Starter | 12; 2,0 V, KW |
| Battery | 12, 925 ССА V |
| Raise | 3,5 sec |
| Lower | 2,2 sec |
| Roll back | 2,0 sec |
| Dump | 1,4 sec |
